    15.6 Inch 1920*1080 AUO LCD Module 500cd/M2 High Brightness With Backlight Driver

    Ask Lasest Price
    Brand Name : DYMONA
    Model Number : M156X60-156-0601
    Certification : CE,SGS,ROHS,ISO9001
    Price : Negotiable price
    Payment Terms : L/C, T/T,Payyal
    Supply Ability : 1KK pcs
    Delivery Time : 5-15 days
    • Product Details
    • Company Profile

    15.6 Inch 1920*1080 AUO LCD Module 500cd/M2 High Brightness With Backlight Driver

    15.6 inch 500 high brightness 1920*1080 LCD module with backlight driver


    Product Description

    item
    value
    Type
    TFT
    Display Size
    15.6 inch
    Supplier Type
    Factory
    Place of Origin
    Guangdong, China
    Brand Name
    AUO
    Size
    15.6 inch
    Resolution
    1920(RGB)x1080 , FHD
    Active Area
    344.16(H) x 193.59(V) mm
    Outline
    363.8(W)×215.9(H)×9.3(D) mm
    Pixel Pitch
    0.17925 x 0.17925 mm
    Arrangement
    R.G.B. Vertical Stripe
    Treatment
    HAZE ,hardness 3H
    Nominal Input Voltage VDD
    3.3 V
    Support color
    16.2M , 99% sRGB
    View angle
    89/89/89/89(Deg)
    Brightness
    500 cd/m²
    Contrast Ratio
    1000:1
    Interface
    eDP (2 Lanes) , 30 pins
    Backlight
    WLED , 50K hours , with LED driver
    Operating temperature
    -20 ~ +70 (℃)
    Storage temperature
    -20 ~ +70 (℃)
    Response time
    25ms
    Weight
    660g
    Display mode
    AHVA , Normally black
    RoHS Compliance
    Yes

    Our Advantage

    For LCD Display:

    After almost 10 years of mature technology developed by the factory, a color screen with an all-glass structure is made;

    Support Custom:
    Customized LCD Size & Resolution / Customized Interface and Pins definition / Customized FPC Shape and Material;

    FPC design:
    Achieve micron level ultra-fine circuit, stable function;


    Product Application

    Our product have a wide range of industrial , instrument , medical , electronic equipment and other fields like below:

    15.6 Inch 1920*1080 AUO LCD Module 500cd/M2 High Brightness With Backlight Driver

    Packaging & Delivery

    Packaging Details:

    Antistatic bag + Bubble bag + Foam box + Carton box

    Delivery Detail:

    1-3 working days after payment confirmed


    FAQ


    Q: who are we?
    A: We are based in Shenzhen and Anhui, China, start from 2009,sell to Western Europe(30.00%),North America(30.00%),Eastern Europe(10.00%),South America(5.00%),Northern Europe(5.00%),Mid East(4.00%),Southern Europe(1.00%). There are total about 100-350 people in our company.


    Q: how can we guarantee quality?
    A: Always a pre-production sample before mass production;
    Always final Inspection before shipment;


    Q: what can you buy from us?
    A: LCD Displays,Touch panels,LCD controller board,LCD panel,Touch screen


    Q: why should you buy from us not from other suppliers?
    A: Our company is a factory of TFT-LCD modules in China mainland, founded in 2009, the products vary from 2.2 to 43 inches, which include GD(Industrial grade), AV(car class), PID(General Application).


    Q. what services can we provide?
    A: Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery;
    Accepted Payment Currency:USD,CNY,and other currencies
    ;
    Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
    Language Spoken:English,Chinese.
